Uno RFID Prototyping Kit V3

Uno RFID Prototyping Kit V3

$198.00 AUD
$198.00 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

The Uno RFID Kit V3 is a great all-rounder kit for new tinkerers and experienced Makers alike.  It contains an Uno R4 WiFi, an amazing board to prototyping smart and IoT products that need bluetooth and/or WiFi connectivity.

For added functionality we suggest combining this with add-on modules, including our MP3 Player Add-on Module.

This kit is also used in conjunction with UTS Mechatronics Engineering and UTS Product Design courses.

This kit contains the following components:

  • 1x UNO R4 WiFi Board
  • 1x USB-A Male to USB-C Male Cable
  • 1x USB-A Female to USB-C adapter
  • Breadboards
    • 1x 400-pin breadboard
    • 2x 170-pin breadboards
  • Modules
    • 1x RFID Card reading module (MFRC522), with 0.1” pin headers, RFID Card, and RFID key chain,
    • 1x Joystick module (KY-023)
    • 1x 4x4 button board module
    • 1x Water sensor
    • 1x Temperature and Humidity sensor module (DHT11) (KY-015)
    • 1x RGB LED module (KY-009)
    • 1x RGB LED module (KY-016)
    • 1x Sound Detection module (KY-037)
    • 1x 5V Relay Module (KY-019)
    • 1x IR Remote Controller (AAA Batteries not included) with IR Receiver
    • 1x IR Line Following Module (KY-033)
    • 1x Bi-directional Logic Level Shifter
    • 1x XC9044 DS3231 Real Time Clock***
  • Jumper Cables
    • 40x DuPont Male-to-Male Cables
    • 30x BreadBoard Wire Jumpers
  • Visual Outputs
    • 1x 16x2 LCD Display (LCD1602) presoldered with the 8-Bit I/O Expander chip – PCF8574 (to control of the 16x2 LCD display over I2C)
    • 1x Four-Digit 7-segment display with decimal point
    • 4x Single-Digit 7-segment displays with decimal point
    • 1x 8x8 LED matrix display - With separated MAX7219 Chip module
    • 1x GC9A01 1.28" Round LCD Display
  • Motors
    • 1x 9G Servo motor (SG90)
    • 1x Stepper motor (28BYJ-48) with motor driver module (ULN2003)
  • Components
    • 1x Passive 5V unsealed piezo buzzer - datasheet
    • 1x Active 5V potted sealed piezo buzzer (washable, but keep sticker on when washing)
    • 2x Tilt switch, ball type (AETHDX SW-520D) - datasheet
    • 3x Photoresistors (LDR)
    • 4x Push-button switches with coloured plastic caps (OMRON B3F-4055)
    • 1x 10kR Carbon Film Potentiometer
    • 1x 5mm High-speed IR Photodiode/Flame Sensor (BPV10NF)
    • 1x 9V battery connector with DC Barrel Jack
    • 1x IR Remote Control Receiver (VISHAY TSOP382)
    • 1x 8-Pin Shift Register (74HC595) - datasheet
    • 1x Temperature Sensor (LM35) - datasheet
    • 1x 40-pin snappable male header
    • 1x Reed Switch (Hermetically sealed glass)
    • 2x VISHAY TCST2103 Photointerruptors
  • LED Pack, containing:
    • 10x Red LEDs,
    • 10x Yellow LEDs,
    • 10x Green LEDs,
    • 10x Blue LEDs, and
    • 1x RGB LED.
  • Resistor Pack, containing:
    • 10x 220R 5% tolerance,
    • 10x 330R 5% tolerance,
    • 10x 360R 5% tolerance,
    • 10x 470R 5% tolerance,
    • 10x 750R 5% tolerance,
    • 10x 1kR 5% tolerance,
    • 10x 10kR 5% tolerance.
  • Miscellaneous
    • 1x Mini Philips (PH1) Screwdriver (for screwing relay terminals, servo arm and mounts, turning trim potentiometers)
    • 1x Resistor Colour Code reference card

***WARNING:  KEEP THE XC9044 DS3231 REAL TIME CLOCK OUT OF REACH OF CHILDREN.

This kit included a XC9044 DS3231 Real Time Clock which contains a soldered button cell - this is a professional/trade only tool.  This component was added at cost to accommodate for a previously known RTC issue with the Uno R4 board's design.  However, Arduino have fixed this issue with a recent firmware update, and the XC9044 will be removed to enable Uno RFID Kit sales to public.

Button Cell Batteries are hazardous (new or used) and can cause severe or fatal injuries within 2 hours if swallowed or placed inside any part of the body.

By purchasing this product, you are aware that:

  • The XC9044 DS3231 Real-Time Clock may not meet child safety testing requirements as it is not intended to be used by consumers or general public, but rather, is intended to be used in trades, professions or industries in conjunction with the limitations and restrictions listed above.
  • These restrictions are due to a change in Australian legislation in 2022 for button/coin cell batteries.
  • If you no longer require the XC9044 DS3231 Real-Time Clock, please dispose of this safely with battery and e-waste recycling.

Button Battery Warning

By purchasing this product, you understand and agree to these conditions.

If it is suspected a battery (of any type) has been consumed or inserted, seek medical attention immediately. Emergency hotlines are listed below:

  • Australia: Emergency Services (000), and 24-hour Poisons Information Centre on 131126.
  • New Zealand: Emergency Services (111), and 24-hour Poisons Information Centre on 0800 764 766.
  • For other countries: contact your local medical emergency department.



View full details
